灯具采用模组化设计，现场可自由拆卸并更换反射器和灯体，从而实现多种规格及出光方式的自由切换。全新的隐光技术赋予良好的防眩光性能及颜色一致性控制，具有舒适的出光效果，主要适用于酒店，别墅及商业空间等室内场所。
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
SLN Surface Mounted N series | 3 3” | 6 Rectangular Trimless | LM08 COB 8W | E On-Off D 0-10V Dimming | S 8° | 27 2700K 30 3000K 35 3500K 40 4000K 50 5000K | B Black S Specular | WT White BK Black |
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
SLN Surface Mounted N series | 3 3” | 6 Rectangular Trimless | LM07 COB 7W LM10 COB 10W LM13 COB 13W | E On-Off D 0-10V Dimming | N 13° 1 18° 2 28° 3 36° 5 50° | 27 2700K 30 3000K 35 3500K 40 4000K 50 5000K | B Black S Specular | WT White BK Black |
示例：SLN36-LM07E-N30SWT
注：8°、13°和18°出厂默认带蜂窝格栅
