ELANA Pro圆形筒灯，完美融合下照和调角功能一体化，让您不再为选型而纠结。通过透镜精准配光，并搭配高品质反射器，带来舒适视觉感受并保证光斑的完整性。特别适用于高档酒店，商业及办公等公共空间。
下照的稳定、调角的灵活，兼而有之
蜂窝+40°防眩光角反射器，双重保障，提供极致舒适视觉体验
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
DLH Downlight H series | 2 2” | 1 Round Trim | LM05 COB 5W LM07 COB 7W | E On-Off D 0-10V Dimming | 1 15° 2 24° 3 36° 5 50° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
DLH Downlight H series | 2 2” | 1 Round Trim | LM07 COB 7W | A DALI N Driver | 1 15° 2 24° 3 36° 5 50° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
DLH Downlight H series | 3 3” | 1 Round Trim | LM07 COB 7W LM10 COB 10W LM13 COB 13W | E On-Off D 0-10V Dimming | 1 15° 2 24° 3 36° 4 45° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
Model | Size | Trim | LED | Driver | Beam | CCT | Reflector | Finish |
DLH Downlight H series | 3 3” | 1 Round Trim | LM13 COB 13W | A DALI N Driver | 1 15° 2 24° 3 36° 4 45° | 27 2700K 30 3000K 40 4000K | B Black S Specular | WT White |
示例：DLH31-LM10-E230SWT， 15°出厂自带蜂窝，其他角度不带。
