更加灵活、更加智能、更加出彩的MERE 轨道射灯。拥有丰富的光学配置、色温以及配件选择， 更有可以 DIY的智能控制模块。 创新设计的0-10V&旋钮调光二合一功能，让现场系统与个体的调试更加灵活、便捷。
MERE
Model | LED | Dimming | Beam | CRI | CCT | Finish |
TL35S MERE | LM10 COB 10W | D 0-10V+ On-board A DALI | 1 12° 2 24° 3 36° 5 50° W Wash F 15°- 50° | 9 90 A 97 | 27 2700K 30 3000K 35 3500K 40 4000K | WT White BK Black |
Model | LED | Dimming | Beam | CRI | CCT | Finish |
TL36S MERE | LM12 COB 12W LM18 COB 18W | D 0-10V+ On-board A DALI | 1 12° 2 24° 3 36° 5 50° W Wash F 15°- 50° | 9 90 A 97 | 27 2700K 30 3000K 35 3500K 40 4000K | WT White BK Black |
Model | LED | Dimming | Beam | CRI | CCT | Finish |
TL37S MERE | LM18 COB 18W LM26 COB 26W LM32 COB 32W LM38 COB 38W | D 0-10V+ On-board A DALI | 1 12° 2 24° 3 36° 5 50° W Wash F 15°- 50° | 9 90 A 97 | 27 2700K 30 3000K 35 3500K 40 4000K | WT White BK Black |
Model | LED | Dimming | Beam | CRI | CCT | Finish |
TL38S MERE | LM38 COB 38W LM48 COB 48W LM58 COB 58W | D 0-10V+ On-board A DALI | 1 12° 2 24° 3 36° 5 50° W Wash F 15°- 50° | 9 90 A 97 | 27 2700K 30 3000K 35 3500K 40 4000K | WT White BK Black |
Model | LED | Dimming | Beam | CRI | CCT | Finish |
TL38S MERE | LM10 COB 10W | D 0-10V+ On-board A DALI | V 2° | 9 90 A 97 | 27 2700K 30 3000K 35 3500K 40 4000K | WT White BK Black |
示例：TL38SLM48-D-2930WT
