HLSE A系列线条灯，出光均匀无光点，Ra>90，具有很高的色彩还原度，双端底部快接头，搭配安装卡件使用方便快捷。专为 小型暗槽、勾边装饰、发光天棚等室内场所设计，适用于酒店别墅、商业空间、公共场馆等场所。
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A1 宽12mm高15mm | SG |
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M 13 13W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A2 宽16mm扇形 | SG |
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M 13 13W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A3 宽17mm高15mm | SG |
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M 13 13W/M 17 17W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A4 宽20mm高27mm三面出光 | SG |
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M 13 13W/M 17 17W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A5 宽20mm高27mm弧形出光 | SG |
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M 13 13W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A6 宽20mm高20mm三面出光 | SG |
Model | LED | Length | CRI | CCT | Series | Finish |
HLSE 硬灯条 | 06 6W/M 10 10W/M 13 13W/M | 10 1010mm | 9 90 | 27 2700K 30 3000K 40 4000K | A7 宽20mm高20mm弧形三面出光 | SG |
示例：HLSE-0610-927A1SG, 1）仅支持白光规格，底部快接头出线; 2）若需要其他功率、色温及长度，请咨询WAC
